0.3mm*5mm UNS R30035 Flat Nickel Chrome Wire

Name: 03mm5mm UNS R30035 Flat Nickel Chrome Wire
Brand: ohmalloy
Price: 21 USD

China 0.3mm*5mm UNS R30035 Flat Nickel Chrome Wire wholesale

Brand Name : ohmalloy

Model Number : 104B

Certification : ISO CE

Place of Origin : China

MOQ : 10KG

Price : USD21/kg~USD27/kg

Payment Terms : L/C, T/T,

Supply Ability : 8000 kgs per week

Delivery Time : within 15 days after payment

Packaging Details : spool or be customized by the clients' demand.

Chemical Composition : 30%Ni 20%Cr balance iron

Size : 0.3mm*5mm

Material : Alloy

Shape : ribbon

Application : sealer heating ribbon

resistivity(μΩ.m) : 1.04

Tensile Strength (≥ MPa) : 675

Elongation (≥ %) : 20

yield strength (≥ MPa) : 340

density (g/cm3) : 7.9

working temperature(℃) : 1100

OEM : available

annealing treatment : hydrogen annealing

surface treatment : bright and soft

certificate : SGS, ISO

Contact Now

0.3mm*5mm UNS R30035 flat wire nickel chrome 30/20 alloy for sealer heating ribbon

Ohmalloy104B
(Common Name: Ni30Cr20,Nikrothal 30, N3, HAI-NiCr 30, Resistohm 30,30-20 Ni-Cr,Nikrothal 3.)
OhmAlloy104B is a nickel-chromium alloy (NiCr alloy) characterized by High resistivity, good oxidation resistance,very good form stability,good ductility and excellent weldability. It is suitable for use at temperatures up to 1100°C.
Typical applications for OhmAlloy104B are used in olid hot plates,open coil heaters in HVAC systems,night-storage heaters,convection heaters,heavy duty rheostats and fan heaters. And also used for heating cables and rope heaters in defrosting and de-icing elements,electric blankets and pads, car seats,baseboard heaters,floor heaters and resistors.

Normal composition%

C	P	S	Mn	Si	Cr	Ni	Al	Fe	Other
Max
0.08	0.02	0.015	1.00	1.0~2.0	18.0~21.0	30.0~34.0	-	Bal.	-

Typical Mechanical properties(1.0mm)

Yield strength	Tensile Strength	Elongation
Mpa	Mpa	%
340	675	35

Typical Physical properties

Density (g/cm3)	7.9
Electrical resistivity at 20℃(Ωmm2/m)	1.04
Conductivity coefficient at 20℃ (WmK)	13

Coefficient of thermal expansion
Temperature	Coefficient of Thermal Expansion x10-6/℃
20 ℃- 1000℃	19

Specific heat capacity
Temperature	20℃
J/gK	0.50

Melting point (℃)	1390
Max continuous operating temperature in air (℃)	1100
Magnetic properties	non-magnetic

Temperature Factors Of Electrical Resistivity

20℃	100℃	200℃	300℃	400℃	500℃	600℃
1	1.023	1.052	1.079	1.103	1.125	1.141
700℃	800℃	900℃	1000℃	1100℃	1200℃	1300℃
1.158	1.173	1.187	1.201	1.214	1.226	-

Style of supply

Alloys Name	Type	Dimension
OhmAlloy104BW	Wire	D=0.03mm~8mm
OhmAlloy104BR	Ribbon	W=0.4~40	T=0.03~2.9mm
OhmAlloy104BS	Strip	W=8~250mm	T=0.1~3.0
OhmAlloy104BF	Foil	W=6~120mm	T=0.003~0.1
OhmAlloy104BB	Bar	Dia=8~100mm	L=50~1000
